QUALITY ASSURANCE

One thing we learned over the years is that making it right and verifying it is right can be two entirely different things.  Therefore, we have always striven to ensure we have the capability of not only making the parts correct, but certifying they are correct.  Our inhouse, climate-controlled Metrology Lab is equipped with a state-of-the-art Coordinate Measuring Machine as well as a non-contact Vision Inspection System and the latest CMM Manager software to run both.  The CMM and Vision Inspection System are calibrated annually to ISO/NIST standards and all other measuring devices are continuously calibrated inhouse to certified precision gauges and standards.  Our QA System includes first article inspections, continuous in process inspections on the shop floor, and final, complete dimensional inspection in the lab before delivery.

 SETTING NEW STANDARDS

METROLOGY LABORATORY-1.jpg
METROLOGY LABORATORY-1.jpg
gauge pins.jpg
Illuminated Rock
SPECIFICATIONS

250 x 200 x 200 mm​

.0064/.00025

.0010/.00004

.0013/.00005

.0012/.00005

.0014/.00005

Renishaw® TP200/TP20

STROKE (X, Y, Z)

Volumetric Deviation

  (mm/in)

X Axis Deviation (mm/in)

Y Axis Deviation (mm/in)

Z Axis Deviation (mm/in)

Repeatability (mm/in)

Touch probe

SPECIFICATIONS

STROKE (X, Y, Z)

Volumetric Deviation

(mm/in)

X Axis Deviation (mm/in)

Y Axis Deviation (mm/in)

Z Axis Deviation (mm/in)

Repeatability (mm/in)

Touch probe

500 x 400 x 400 mm​

0.0081 / 0.00032

0.0019 / .00008

0.0036 / 0.00014

0.0012 / 0.00005

0.0020 / 0.00008



Renishaw® TP20

INSPECTION EQUIPMENT
